Toshiba

BV400T series

Powerful and scalable

The BV400 series is Toshiba’s most advanced desktop printer series, consisting of nine different models across the BV400D series (five models) and BV400T series (four models). Each have a small footprint combined with intelligent design which brings simplicity and efficiency for the ultimate user experience. Enhanced connectivity features enable these printers to be integrated into various networks and, thanks to print language emulations, into almost every print scenario. The robustness of the printer series offers high print quality and performance comparable to mid-ranged printers.

Category: Desktop Printers Brand: Toshiba

Description

Compact and sleek design with a small footprint
Intuitive and clear user experience
Vast print languages and emulations
RFID encoding
SOTI Connect certified for IoT device management

Key Specifications

	BV410T-GS02 (White Case)	BV410T-TS02 (White Case)	BV420T-GS02 (Black Case)	BV420T-TS02 (Black Case)
Printing Method	Thermal transfer, direct thermal	Thermal transfer, direct thermal	Thermal transfer, direct thermal	Thermal transfer, direct thermal
Print Head Type/Alignment	Flat head	Flat head	Flat Head	Flat Head
Resolution	203 dpi (8 dots/mm)	300 dpi (11.8 dots/mm)	203 dpi (8 dots/mm)	300 dpi (11.8 dots/mm)
Interface	2x LED, 3x key, with LCD	2x LED, 3x key, with LCD	3x LED, 2x key	3x LED, 2x key
Print Width/Print Length	Width: 108 mm Length: Batch – 6-997.9 mm; Cut – 20.4-997.9 mm¹; Peel-off – 21.4-148.4 mm¹	Width: 105.7 mm Length: Batch – 6-997.9 mm; Cut – 20.4-997.9 mm¹; Peel-off – 21.4-148.4 mm¹	Width: 108 mm Length: Batch – 6-997.9 mm; Cut – 20.4-997.9 mm¹; Peel-off – 21.4-148.4 mm¹	Width: 105.7 mm Length: Batch – 6-997.9 mm; Cut – 20.4-997.9 mm¹; Peel-off – 21.4-148.4 mm¹
Print Speed	7 ips (177.8 mm/s)	5 ips (127 mm/s)	7 ips (177.8 mm/s)	5 ips (127 mm/s)
Dimensions & Weight	200 x 267 x 198.3 mm; 2.9kg	200 x 267 x 198.3 mm; 2.9kg	200 x 267 x 198.3 mm; 2.9kg	200 x 267 x 198.3 mm; 2.9kg
Ribbon Lengths	Width: 40-110 mmMax. Length: 300 m	Width: 40-110 mmMax. Length: 300 m	Width: 40-110 mmMax. Length: 300 m	Width: 40-110 mmMax. Length: 300 m
Emulations	ZPL II, DPL, SBPL, EPL2, IPL	ZPL II, DPL, SBPL, EPL2, IPL	ZPL II, DPL, SBPL, EPL2, IPL	ZPL II, DPL, SBPL, EPL2, IPL
Interface /Options	Interfaces: USB 2.0, USB Host, Ethernet 10/100 Base T (IPv4 & IPv6), Bluetooth V5.2 BR/EDR with MFi certified¹⁾²⁾, serial port¹⁾Options: UHF RFID kit, full cutter module, partial cutter module, peel-off module, serial interface board, Bluetooth module, AC adapter cover, external media stand, print head kits for resolution change	Interfaces: USB 2.0, USB Host, Ethernet 10/100 Base T (IPv4 & IPv6), Bluetooth V5.2 BR/EDR with MFi certified¹⁾²⁾, serial port¹⁾Options: UHF RFID kit, full cutter module, partial cutter module, peel-off module, serial interface board, Bluetooth module, AC adapter cover, external media stand, print head kits for resolution change	Interfaces: USB 2.0, USB Host, Ethernet 10/100 Base T (IPv4 & IPv6), Bluetooth V5.2 BR/EDR with MFi certified¹⁾²⁾, serial port¹⁾Options: Full cutter module, partial cutter module, peel-off module, serial interface board, Bluetooth module, AC adapter cover, external media stand, print head kits for resolution change	Interfaces: USB 2.0, USB Host, Ethernet 10/100 Base T (IPv4 & IPv6), Bluetooth V5.2 BR/EDR with MFi certified¹⁾²⁾, serial port¹⁾Options: Full cutter module, partial cutter module, peel-off module, serial interface board, Bluetooth module, AC adapter cover, external media stand, print head kits for resolution change
