RFID Features
- Prints and encodes tags with a minimum pitch of 0.6″/16 mm (without cutter option)
- Adaptive Encoding Technology simplifies RFID setup and eliminates complex RFID placement guidelines
- RFID job monitoring tools track RFID performance
- RFID ZPL® commands provide compatibility with existing Zebra RFID printers
- Support for industry standard multi-vendor chip-based serialization (MCS)
- Supports block permalocking of user memory compatible with ATA Spec 2000
- Integrated ThingMagic® RFID Reader/Encoder
Printer Features
- Tool-less printhead and platen replacement
- OpenACCESS™ for easy media loading
- Quick and easy ribbon loading
- Simplified calibration of media
- Quad connectivity: USB, Parallel, Serial, and Ethernet
- Real-time clock
- LCD User Interface
- Zebra E3 Printhead Energy Contro
- ENERGY STAR® qualified
- Link-OS™enabled
- Print Touch™ app
- Unicode compliant for multi-language printing
- 16 resident expandable ZPL II® bitmap fonts
- Two resident scalable ZPL fonts
- Auto-switching 100-240V power supply
- Head-up sensor
- Standard tear-off mode feature
- 3″ media core adaptor
- Zebra printer drivers for Windows™
Printer Specifications
- **Resolution:**
- 203 dpi (8 dots/mm)
- 300 dpi (12 dots/mm) optional
- **Memory:**
- 128 MB Std SDRAM memory (4 MB available to user)
- 256 MB Std Flash memory (56 MB available to user)
- Print length: **39″ (990 mm) maximum**
- Programmable print speeds of **2, 3, 4, 5, & 6 ips** (51, 76, 102, 127, & 152 mm/s)
- **Media sensors:** Full width reflective and multiposition transmissive sensors
Media Characteristics
- Maximum label and liner length: **39″/990 mm** (maximum non-continuous)
- Maximum label and liner width: **0.75″/19 mm to 4.25″/108 mm**
- **Label Length:**
- Minimum using tear off mode: .25″ (6.3 mm)
- Minimum with label present sensor used – 0.50″ (12.7 mm)
- Minimum with cutter – 1.0″ (25.4 mm)
- Maximum media roll size: **5″/127 mm O.D.**
- Media thickness: **0.003″/0.08 mm to 0.012″ (0.305 mm)**
- Media types: Roll-fed or fan-fed, die-cut or continuous direct thermal labels with or without black line, tag stock, continuous receipt paper, wristbands
Ribbon Characteristics
- Outside diameter: **1.36″/35 mm**
- Standard length: **244’/74 mm**
- Ratio: 1:1 media to roll to ribbon
- Width: **1.33″/33.8 mm to 4.3″/109.2 mm**
- Core inner diameter: **0.5″/12.7 mm**
Environmental
Storage Temperatures: **-40° F/-40° C to 140° F/60° C**
Physical Characteristics
- Width: **7.6″/193 mm**
- Height: **7.5″/191 mm**
- Depth: **10.0″/254 mm**
- Weight: **4.9 lbs/2.2 kg**
Barcodes/Symbologies
- Barcode Ratios: **2:1 (non-rotated) and 3:1**
- Linear Bar Codes: Code 11, Code 39, Code 93, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, EAN-14, UPC-A and UPC-E with EAN 2 or 5 digit extensions, Plessey, POSTNET, Standard 2 of 5, Industrial 2 of 5, Interleaved 2 of 5, LOGMARS, MSI, Codabar, and GS1 DataBar (formerly RSS)
- 2-Dimensional: PDF417, MicroPDF-417, Code 49, Maxicode, Codablock, Data Matrix, QR code, Aztec
Options and Accessories
- 300 dpi print resolution printing for fine detail and crisp images
- Wireless—802.11 a/b/g/n and Bluetooth 3.0
- Dispenser—label peel and present with present sensor
- Cutter for various media types
- ZKDU and KDU Plus™ keyboard display units for stand-alone printing solutions
